Image Service (Ilum)

Ilum is b10cks' built-in image transformation service. It resizes, crops, and re-encodes assets on the fly via URL path operations — no pre-generated renditions, no external service, no upload-time configuration. You describe the image you want in the URL; Ilum computes it on first request and every subsequent request is served from cache.

This design has a few practical consequences:

• The URL is the API. There's no SDK call to make and nothing to configure per asset — any variant you can express as an operation string exists the moment you request it.
• Variants are free until used. Because nothing is pre-generated, adding a new breakpoint to your frontend doesn't require reprocessing your media library.
• URLs are immutable per asset version. Replacing an asset produces a new asset path, so transformed URLs can be cached forever (Cache-Control: immutable, 1-year max-age) and put behind any CDN.

Under the hood Ilum uses libvips (with an ImageMagick fallback), which streams pixels instead of loading full bitmaps — resizing a 40-megapixel photo takes tens of milliseconds and little memory. Oversized sources (>100 MP by default) are rejected before decoding as a decompression-bomb guard.

URL anatomy

https://<ilum-host>/<storage>/<space>/<assetId>/<filename>                 # original
https://<ilum-host>/<storage>/<space>/<assetId>/<filename>/<operations>   # transformed

Asset fields deliver a full_path that already contains everything up to the filename. To transform, append a / and a comma-separated list of operations; format and quality go in the query string:

…/IMG_1505.jpeg                                  # original, streamed as-is
…/IMG_1505.jpeg/w_800                            # 800px wide, proportional
…/IMG_1505.jpeg/w_800,h_450,c_fill,g_face        # exact 800×450, cropped around faces
…/IMG_1505.jpeg/w_1200,h_630,c_fill?format=jpg&quality=80

A real example against a live asset:

https://app.b10cks.com/ilum/01k13p9615ysd6g3zzffkc527j/01k119agamfvn54vb7tnjn87zr/01kxx5prnge07etb8w5682h18v/IMG_1505.jpeg/w_600,h_600,c_fill,g_face

Each operation is key_value; order within the list doesn't matter. Invalid combinations return a 422 JSON error explaining what's wrong rather than a broken image.

Playground

Build an operation string against two live demo assets and watch the result update. The generated URL is exactly what you'd put in an <img src>.

Source image

Presets

Width w

Height h

Crop mode cnone (resize)fillfitcrop (manual)

Gravity gnonefacecenterautofocal point

Formatdefault (webp)webpavifjpgpng

Quality

…/IMG_1505.jpeg/w_600,h_400,c_fill,g_face

Operations reference

Path operations (comma-separated, after the filename):

Op	Example	Meaning
w_{px}	w_800	Target width in pixels (max 5000)
h_{px}	h_450	Target height in pixels (max 5000)
c_{mode}	c_fill	Crop mode: fill, fit, or crop
g_{gravity}	g_face	Gravity for fill: face, center, auto, or a focal point
x_{px} / y_{px}	x_120,y_40	Top-left offset for manual crop
tw_{px} / th_{px}	tw_400,th_300	Target size when combining crop with a resize (must be set together)

Query parameters:

Param	Example	Meaning
format	format=webp	Output format: webp, avif, jpg, png
quality	quality=80	Encoder quality, 1–100

Dimensions beyond the configured maximum (5000px by default) are clamped, not rejected — a w_9000 request silently becomes w_5000.

Crop modes

No c — plain resize. w or h alone resizes proportionally; the other dimension follows the aspect ratio. Both together resize to fit within the w×h box without cropping — the result matches at least one of the two dimensions exactly.

…/photo.jpg/w_800          # 800px wide, height follows
…/photo.jpg/h_600          # 600px tall, width follows
…/photo.jpg/w_800,h_600    # fits inside 800×600, aspect preserved

c_fill — fill the exact box. The result is always exactly w×h; whatever doesn't fit the target aspect ratio is cropped away. Requires both w and h. Where it crops is decided by gravity:

• g_face — detects faces and keeps them in frame. The go-to for avatars and team photos.
• g_auto — crops around the most visually salient region (entropy/attention based). A good default for arbitrary editorial images.
• g_center — plain center crop.
• g_{X}p_{Y}p — a fixed focal point in percent of the source image, e.g. g_30p_60p keeps the point at 30% from the left and 60% from the top in frame across every target aspect ratio. Ideal when editors set a focal point once and the frontend renders many crops.
• No g — behaves like a center-weighted fit.

…/team.jpg/w_400,h_400,c_fill,g_face        # square avatars
…/hero.jpg/w_1600,h_400,c_fill,g_30p_60p    # ultrawide banner, subject stays in frame

c_fit — fit within the box. Same as the no-c two-dimension resize, but valid with a single dimension too. Never crops, never upscales beyond what you ask for.

c_crop — manual crop. Cuts a w×h region starting at offset x/y (source pixels, default 0,0). Add tw/th to also resize the cropped region — e.g. cut a 800×600 region, then downscale it to 400×300:

…/photo.jpg/x_200,y_150,w_800,h_600,c_crop              # cut region, keep size
…/photo.jpg/x_200,y_150,w_800,h_600,c_crop,tw_400,th_300 # cut region, then resize

Use manual crop when coordinates come from your own UI (an editor-drawn crop box); use fill + gravity for everything automated.

Formats and quality

When any transformation is requested and no format is given, Ilum re-encodes to the instance default (webp out of the box) — so w_800 alone already gives you a modern format. Request the untouched original by using the URL without operations.

Format	Default quality	Notes
webp	85	Default output; broad support, good compression
avif	85	Best compression; encoding is slower (first request only)
jpg	85	For consumers that need universal support (e.g. some OG-image scrapers)
png	90	Lossless-ish; use for screenshots/diagrams with hard edges

Animated sources (GIF, animated webp) keep their animation: if the target format can't animate, Ilum falls back to gif automatically.

quality trades file size against fidelity. For photographic content quality=60–75 in webp/avif is usually indistinguishable at display size; the default 85 is conservative.

Recipes

Responsive srcset — one asset, many widths, browser picks:

<img
  src="…/hero.jpg/w_1280"
  srcset="…/hero.jpg/w_640 640w, …/hero.jpg/w_1280 1280w, …/hero.jpg/w_1920 1920w"
  sizes="(max-width: 768px) 100vw, 1280px"
  alt="…"
>

Art direction — different aspect ratios per breakpoint, focal point keeps the subject framed in all of them:

<picture>
  <source media="(max-width: 640px)" srcset="…/hero.jpg/w_640,h_800,c_fill,g_30p_40p">
  <img src="…/hero.jpg/w_1600,h_640,c_fill,g_30p_40p" alt="…">
</picture>

Social / OG images — scrapers prefer jpg and a fixed 1200×630:

…/cover.jpg/w_1200,h_630,c_fill,g_auto?format=jpg&quality=80

Avatars at every size from one upload:

…/portrait.jpg/w_48,h_48,c_fill,g_face      # comment thread
…/portrait.jpg/w_200,h_200,c_fill,g_face    # profile page

Framework integration

For Nuxt, a ready-made @nuxt/image provider generates these URLs (including responsive srcset) — see the Nuxt guide. In other frameworks, build the operation string yourself or port the provider (it's ~100 lines of URL assembly).

Poster frames

Video assets get thumbnail frames extracted at upload time. Those frames are addressable through the same URL grammar by appending /poster, which turns a video URL into an image URL — every transformation and query parameter above still applies. Other non-image assets (audio, PDFs, archives, …) get the same /poster sub-path once a custom poster (below) has been uploaded for them:

…/clip.mp4/poster                                  # first frame, default format
…/clip.mp4/poster/w_1200,h_675,c_fill              # poster cropped to 16:9
…/clip.mp4/poster/w_640?format=jpg&quality=70      # jpg poster for older players
…/clip.mp4/poster?frame=2                          # a later capture position

frame indexes the stored captures in capture order (default 0); an out-of-range index falls back to the first. Assets without any stored frame return 404.

<video src="…/clip.mp4" poster="…/clip.mp4/poster/w_1280,h_720,c_fill" controls></video>

Custom posters. Editors can set a hand-picked still via POST /mgmt/v1/spaces/{space}/assets/{asset}/poster (multipart, field poster, raster image formats only). This works for any non-image asset — videos, audio, PDFs, archives — so a zip or PDF can carry a designed cover instead of a generic file icon. Afterwards /poster serves the uploaded image; for videos the generated captures are stashed rather than deleted, and DELETE …/assets/{asset}/poster removes the custom poster and restores them. Non-media assets only expose /poster while a custom poster is set — thumbnail metadata from other sources is never served.

Because the /poster URL stays the same when the poster changes, unpinned poster responses are cached for an hour and revalidate with an ETag. The management API exposes a poster_url on every asset that pins the current poster with a v parameter; pinned URLs are cached immutably like any other transformation.

Caching and delivery

A given operations string is computed once per edge cache entry: responses carry Cache-Control: public, max-age=31536000, immutable, an ETag, and permissive CORS headers, so with a CDN in front of the Ilum host every variant becomes an edge hit after its first request. (There is no server-side derivative store — the CDN is the cache, so an origin with no CDN in front recomputes on every request.)

Non-image assets

Anything that isn't an image — video, audio, PDFs, documents — is proxied byte-for-byte rather than transformed, with the semantics media players need:

• Byte ranges. Range requests are answered with 206 Partial Content and a Content-Range. This is what makes video seekable, and it's a hard requirement for playback in Safari, which probes with Range: bytes=0-1 before it will play anything. Accept-Ranges: bytes is advertised on full responses, unsatisfiable ranges return 416, and If-Range is honoured. On S3-backed storage the offset is pushed down into the GetObject call, so the origin never transfers bytes the client didn't ask for.
• Conditional requests. Responses carry an ETag (the stored checksum where one exists) and Last-Modified; If-None-Match / If-Modified-Since are answered with 304. Untransformed files are not marked immutable by default, so a revalidation path always exists.
• Downloads. Append ?download=1 to get Content-Disposition: attachment with the original upload filename instead of inline rendering.
• Hardening. Every response carries nosniff, and every response carries the restrictive sandbox CSP unless its content type is on a short exemption allow-list. Today that list holds only application/pdf, which is exempt because sandbox breaks the browser's built-in PDF viewer and that viewer already isolates embedded script from the embedding origin. The allow-list polarity is deliberate: these routes serve user-uploaded bytes from an origin shared with the management UI, so a type nobody has vetted stays sandboxed by default.
